Full Automatic Touchless Car Washer With Single Arm Total Power 16KW

Certification : CE

MOQ : 1

Payment Terms : L/C, D/A, D/P, T/T

Delivery Time : 25

Place of Origin : Guangdong, China

Brand Name : WinTai

Model Number : T12

Packaging Details : Standard export packaging

Supply Ability : 500 Set/Sets per Month

Price : $18,500.00/sets >=1 sets

Color : Blue

Material : Metal

Fan Motor Power : 4KW/set x3sets

Water Pump Motor Power : 100Bar working pressure, Max. 120Bar

Total Power : 16KW

Air Switch : 100A

Power Requirement : AC380V/50Hz/3Ph

Total Weight/volume : ≥2100kgs/≥7.5cube

Machine Size(L*W*H) : L*W*H=7500*3500*3200mm

Electricity Consumption : Approx. 0.75KW/car

Water Consumption : Approx. 150L/car

Max Vehicle Suitable : L*W*H=5600*2100*2080mm

Shampoo Consumption : Approx. 40ml/car

Foam Consumption : Approx. 40ml/car

Water Wax Consumption : Approx. 80ml/car

Magic color bubble consumption : Approx. 80ml/car

Time Consumption : 120s/car

Contact Now

Full Automatic Touchless Car Washer With Single Arm Total Power 16KW
Product Overview
Full automatic brushless car washing machine single arm automatic car wash machine with advanced touch screen controls for automated chemical consumption based on vehicle dirt level.
Full Automatic Touchless Car Washer With Single Arm Total Power 16KW
Technical Specifications
Item Parameters Function Remark
Installation Size (L*W*H) 7500*3500*3200mm (24.6ft *11.48ft *10.5ft) Chassis wash function Yes
Max. Car Size 5600*2100*2080mm (18.37ft *6.89ft *6.82ft) 360-degree high pressure water wash Yes
Shampoo Consumption Approx. 40ml/car Foam function Yes
Foam Consumption Approx. 40ml/car All degree rotary high pressure flushing Yes
Water Wax Consumption Approx. 80ml/car Shampoo function Yes
Magic color bubble consumption Approx. 80ml/car Wax rain Yes
Water Consumption Approx. 150L/car Built in 4Pcs * 3KW Air dry Yes
Electricity Consumption Approx. 0.75KWH/car Self-guided parking system Yes
Time Consumption 4.5min/car, 8 hours 100 cars Vehicle length detection Yes
Air Switch 100A air switch LED indication light guide system Yes
Power Supply Requirements AC380V/50Hz/3Ph/16KW, 14smm copper cable Operation permission setting function Yes
Water Pump Motor Power Germany PINF Pump 15KW/100Bar working pressure, Max. 120Bar Self-service payment system Yes
Water Pump Motor Power 18.5KW/pressure 130Bar, 10-130Bar Adjustable, Simens Voice Prompts function Yes
Fan Motor Power Built in 4 pcs 3KW blowers total 12KW Vehicle width detection Yes
Remote Control Remote Control Automatically adjust Yes
Central Processing Unit PLC Industrial intelligent digital control system LED alert system Yes
Drive System Variable frequency speed control + digital driver Washing quantity counting function Yes
Detection System Intelligent three-dimensional detection system Fault self-test function Yes
Central Processing unit PLC Industrial intelligent digital control system Wireless remote control system Yes
Drive system Variable frequency speed control + digital servo driver Galvanized frame Yes
Sensing System Ultrasound + Absolute value of the digital encoder, 1 sensors
Product Gallery
Full Automatic Touchless Car Washer With Single Arm Total Power 16KW Full Automatic Touchless Car Washer With Single Arm Total Power 16KW Full Automatic Touchless Car Washer With Single Arm Total Power 16KW Full Automatic Touchless Car Washer With Single Arm Total Power 16KW Full Automatic Touchless Car Washer With Single Arm Total Power 16KW
Manufacturer Profile
Full Automatic Touchless Car Washer With Single Arm Total Power 16KW Full Automatic Touchless Car Washer With Single Arm Total Power 16KW Full Automatic Touchless Car Washer With Single Arm Total Power 16KW Full Automatic Touchless Car Washer With Single Arm Total Power 16KW
Guangzhou Wintai Cartools Co., Ltd is a professional manufacturer of car washing machine equipment established in 2013, integrating R&D, production, sales and service. WINTAI focuses on high-end car washing machine manufacturing and design, and strives to provide consumers with higher quality car washing machine equipment.
Full Automatic Touchless Car Washer With Single Arm Total Power 16KW
The workshop is located in Xi'an and has an export office in Guangzhou. Xi'an is an international transportation hub with strategic advantages for export transportation.
Full Automatic Touchless Car Washer With Single Arm Total Power 16KW
WINTAI specializes in the research and development of fully automatic computer car wash equipment. Based on the absorption of advanced technology from the same industry in the world, WINTAI adopts a unique design concept and combines the domestic car wash market conditions. After years of continuous research, testing and testing, and further innovation, we have developed a new generation of stable T series surrounding high-pressure non-contact wipe-free automatic computer car wash system. It's cost-effective, reliable and with stable performance.
Full Automatic Touchless Car Washer With Single Arm Total Power 16KW
Among them, T9 and WT-390 are the leading products of our company. Both T9 and WT-390 have self-service payment systems. This is a further elimination of labor compared to the traditional car wash industry, and to make up for the short-term business hours. 24h all-day business can solve the problem of car owners car wash time, but also create more benefits for investors.
WT-390 is more inclined to meet the basic needs of the current market. It is a suitable choice for the car wash industry or the general washing station. The T9 has a larger flushing pressure, the maximum flushing pressure can reach 130bar. It's with 4pcs of 5.5kw fans, and the surrounding flushing speed reaches 27 seconds in 360 degrees around the car, its washing speed is faster. Secondly T9 has more washing modes compared to the general car washing machine. The car owner can choose different modes according to actual needs.
Full Automatic Touchless Car Washer With Single Arm Total Power 16KW
In short, both T9 and WT-390 can meet export requirements. We also export these products to Malaysia, Armenia, Kazakhstan, Russia, Nigeria and the vast European countries.
